Agent-Based Simulation Performance
Rigorous bottleneck characterization of large-scale ABM workloads using DAMOV and hardware profiling
Agent-based modeling (ABM) is a bottom-up method for studying complex systems. We model thousands, millions, even billions of individual agents—each one simple, with its own properties and behavior, each interacting with its neighbors. From these local interactions, global complexity emerges.
Presented as a poster at ACACES 2026 (HiPEAC Summer School, Fiuggi, Italy) with a merit-based grant (Sokoli & Yaglikci, 2026).
Why agent-based simulations matter
The ambition is growing: we do not want to simulate just thousands or millions of agents, but billions—the world we live in, at the speed it actually operates, at large scale and in real time. Nobody or any tool can do that today.
The EU recently committed to phasing out animal testing across 15 legislative domains, yet its own funding falls short of that ambition—pointing directly to agent-based simulations as an alternative.
Versatile applications
Agent-based simulations are general. The approach applies everywhere:
Research goal
To reach real-time, billion-agent simulation, we must first understand where performance breaks down. We started simulating real-world use cases to benchmark them, determine whether bottlenecks lie in software (data structures, architecture) or demand hardware acceleration, and guide future co-design.
To our knowledge, this is the first work that rigorously characterizes where agent-based simulations bottleneck at scale—a central contribution of this project.
Methodology
We profiled BioDynaMo, the state-of-the-art agent-based simulation framework developed at CERN, using an epidemiology use case:
- Scale: 10M to 1B agents on Google Cloud C4 VMs (16 cores each)
- Characterization: DAMOV methodology for workload analysis
- Profiling:
perfat 1 Hz to capture hardware metrics in real time during simulation
We derived four metrics for the analysis:
| Metric | What it measures |
|---|---|
| IPC | Instructions per cycle—processor utilization |
| LLC MPKI | Last-level cache misses per kilo-instruction |
| Memory-bound fraction | Share of cycles stalled on memory |
| LFMR | Last-to-first miss ratio—cache line reuse after L1 miss |
Key findings
- IPC sits around 0.4 on a 16-core machine. The processor is mostly idle.
- Memory-bound fraction exceeds 60% at every agent count tested. This is a memory-bound workload.
- LFMR stays above 0.74 across the board. Most L1 misses skip past L2 entirely—the cache line arrives, the processor touches it once, and it is never reused. L2 is largely ineffective for this workload.
- Non-monotonic scaling behavior: performance is worst at 10M agents, best at 50M, and degrades again beyond that. This remains an open question.
- A hard memory ceiling: 200M agents already consumes 58 GB. Memory capacity sets the limit on how far this scales on our machines.
Memory is standing in the way of simulating the world at the speed it runs.
What’s next
- Characterizing locality in agent access patterns
- Validating hardware profiling results against a simulation-based approach
- Extending to GPUs and PIM, where we expect the memory bottleneck to worsen—not improve—once parallelism is fully embraced
Related frameworks & code
- BioDynaMo — state-of-the-art ABM framework (CERN)
- ACACES 2026 profiling study — experiment scripts and analysis
- CARTopiaX — scalable simulation framework
- NeuroDev — neural development simulation
This project bridges agent-based modeling research with computer architecture and performance engineering, connecting to affiliated work on HBM-PIM memory systems.
